| Basic technical parameters | |||||
| Parameter name | Company | Model and specification | |||
| RX06-G6 | RX10-G10 | RX16-G16 | RX25-G25 | ||
| Maximum flow | m3/h | 10 | 16 | 25 | 40 |
| Minimum flow | m3/h | 0.06 | 0.1 | 0.16 | 0.25 |
| Maximum working pressure | kPa | 50 | |||
| Pressure loss | Pa | ≤200 | ≤300 | ||
| Basic error | % | qmin≤q＜qt時(shí)， ±3% | |||
| qt≤q≤qmax時(shí)， ±1.5% | |||||
| Tightness | kPa | Input air 1.5 times the maximum working pressure for three minutes without leakage | |||
| Long term operation performance | / | It shall meet the requirements of national standard GB / t6968-2019 membrane gas meter after running for 5000h under the maximum flow | |||
| Service temperature | ℃ | -10～40 | |||
| Accuracy level | / | 1.5 Grade | |||
